钻杆产品 Drillpipe Product
加重钻杆列表 Heavy Wight Drillpipe List

规格
Nominal size

管体 Pipe body 接头 Tool joint

单根质量
Weight
Kg/Piece

外径
D
(mm)

内径
d
(mm)

 加厚尺寸 Upset dimensioon

螺纹类型
RSC type

外径
DJ
(mm)

内径
ID
(mm)

倒角直径
HSC bevel
dia
DF
(mm)

中部
Center dia.
Dm
(mm)

端部
End dia.
DTE
(mm)

3 1/2 88.9 52.4 116.3 98.4

NC38
(3 1/2IF)

127 55.6 116.3 312
3 1/2 88.9 57.2 116.3 98.4 NC38
(3 1/2IF)		 127 58.7 116.3 282
4 101.6 65.1 114.3 106.4 NC40
(4FH)		 133.4 68.3 127.4 370
4 1/2 114.3 69.9 127 119.1 NC46
(4IF)		 158.8 73 145.3 558
5 127 76.2 139.7 130.2 NC50
(4 1/2IF)		 168.3 77.8 170.7 672
5 1/2 139.7 92.1 152.4 744.5 5 1/2FH 184.2 88.9 170.7 776
6 5/8 168.3 114.3 184.2 171.5 6 5/8FH 203.2 117.5 195.7 964
    Although every effort has been made to ensure accuracy of this catalogued-Master does not guarantee the contents and does not recommend its use for design purposes.DP-M is in no way liable for any damages resulting from use of this catalogue material.
钻杆列表 Drillpipe List
1 2 3 4 5 6 7 8 9 10 11 12 13 14
Designation Pipe body Tool joint

公称尺寸

Nominal

size

公称质量

Nominal

weight

钢级

Grade





加厚形式

Upset type

外径
OD
Ddp
(mm)

壁厚
Wall thickness
t
(mm)

螺纹类型

RSC type

接头外径
OD of PIN
AND bOX
d
(mm)

接头内径
ID of Pin

d(mm)

倒角直径Bevel Dia.
of Pin and
Box
Shoulder
DF(mm)

公接头
大钳空间

Pin tong
LPB(mm)

母接头
大钳空间

Box tong
LPB(mm)

焊颈外径
OD of
upset neck
DTE/DPE
(mm)

扭转强度对比

Torsional
Ration,Pin
to Drill
pipe body

2 3/8 6.65 E
X
G		 EU 60.32 7.11 NC26 85.7
85.7
85.7		 45.45
45.45
45.45		 82.95
82.95
82.95		 177.8
177.8
177.8		 203.2
203.2
203.2		 65.09
65.09
65.09		 1.1
0.87
0.79
2 7/8 10.4 E
X
G
S		 EU 73.02 9.19 NC31 104.8
104.8
111.1		 53.98
50.8
50.8
41.28		 100.41
100.41
100.41
100.41		 177.8
177.8
177.8
177.8		 228.6
228.6
228.6
228.6		 80.96
80.96
80.96
80.96		 1.03
0.9
0.82
0.82
3 1/2 13.3 E
X
G
S		 EU 88.9 9.35 NC38 120.7
127
127
127		 68.26
65.09
61.91
53.98		 116.28
116.28
116.28
116.28		 203.2
203.2
203.2
203.2		 266.7
266.7
266.7
266.7

98.43
98.43
98.43
98.43

0.98
0.87
0.86
0.8
E
X
G		 11.4   127
127
127		 65.09
61.91
53.98		 116.28
116.28
116.28		 203.2
203.2
203.2		 266.7
266.7
266.7		 98.43
98.43
98.43		 0.97
0.83
0.9
15.5 S NC40 139.7 57.15 127.4 177.8 254 98.43 0.87
4 14 E
X
G
S		 IU 101.6 8.38 133.4
133.4
139.7
139.7		 71.44
68.26
61.91
50.8		 127.4
127.4
127.4
127.4		 177.8
177.8
177.8
177.8		 254
254
254
254		 106.36
106.36
106.36
106.36
1.01
0.86
0.93
0.87
E
X
G
S		 EU NC46 152.4 152.4
152.4
152.4		 82.55
82.55
82.55
76.2		 145.26
145.26
145.26
145.26		 177.8
177.8
177.8
177.8		 254
254
254
254		 114.3
114.3
114.3
114.3		 1.43
1.13
1.02
0.94
4 1/2 16.6 E
X
G
S		 IEU 114.3 8.56 158.8
158.8
158.8
158.8		 82.55
72.6
76.2
69.85		 145.26
145.26
145.26
145.26		 177.8
177.8
177.8
177.8

254
254
254
254

 119.06
119.06
119.06
119.06		 1.09
1.01
0.91
0.81
20 E
X
G
S		 10.92 158.75
158.75
158.75
158.75
 76.2
69.85
63.5
57.15

145.3
145.3
145.3
145.3

 177.8
177.8
177.8
177.8		 254
254
254
254		 119.07
119.07
119.07
119.07		 1.07
0.96
0.96
0.81
16.6 E
X
G
S		 EU 9.19 NC50 168.28
168.28
168.28
168.28		 95.25
95.25
95.25
88.9		 154
154
154
154		 177.8
177.8
177.8
177.8		 254
254
254
254		 127
127
127
127		 1.23
0.97
0.88
0.81
20 E
X
G
S		 12.7 168.28
168.28
168.28
168.28		 92.08
88.9
88.9
76.2		 154
154
154
154		 177.8
177.8
177.8
177.8		 254
254
254
254		 127
127
127
127		 1.07
0.96
0.96
0.81
5 19.5 E
X
G
S		 IEU 127 9.19 168.28
168.28
168.28
168.28		 95.25
88.9
82.5
69.85		 154
154
154
154		 177.8
177.8
177.8
177.8		 254
254
254
254		 130.18
130.18
130.18
130.18		 1.23
0.97
0.88
0.81
25.6 E
X
G
S		 12.7 168.28
168.28
168.28
 88.9
76.2
69.85		 154
154
154		 177.8
177.8
177.8		 254
254
254

130.18
130.18
130.18

 1.02
0.96
0.86
0.87
19.5 E
X
G
S		 9.19 5 1/2FH 177.8
177.8
177.8
184.15		 95.25
95.25
95.25
88.9		 170.7
170.7
170.7
170.7		 203.2
203.2
203.2
203.2		 254
254
254
254		 130.18
130.18
130.18
130.18		 1.53
1.21
1.09
0.98
25.6 E
X
G
S		 12.7 177.8
177.8
184.15
184.15		 88.9
88.9
88.9
82.55		 170.7
170.7
170.7
170.7		 203.2
203.2
203.2
203.2		 254
254
254
254		 130.18
130.18
130.18
130.18		 1.21
0.95
0.99
0.83
5 1/2 21.9 E
X
G
S		 139.7 9.17 177.8
177.8
184.15
190.5		 101.6
95.25
88.9
76.2

170.7
170.7
170.7
180.2

 203.2
203.2
203.2
203.2		 254
254
254
254		 144.46
144.46
144.46
144.46
1.11
0.98
1.02
0.96
24.7 E
X
G
S		 10.54 177.8
184.15
184.15
190.5		 101.6
88.9
88.9
76.2		 170.7
170.7
170.7
180.2		 203.2
203.2
203.2
203.2		 254
254
254
254		 144.46
144.46
144.46
144.46		 0.99
1.01
0.92
0.86
